Description
Specifications
| Model No. | A10 KV120 |
|---|---|
| Tube size | 40mm |
| Setup | A10 (Motor)+14S FOC 100A (ESC)+MF3424P (Prop) |
| Wire material,wire gauge, color | Power wires：12#AWG red & blackSignal wires: 5P Teflon |
| Recommended battery | 12~14S (LiPo) |
| Wire length | 1230±5mm |
| Rated thrust | 7~11kg |
| Weight | 1520±2%g (incl. Wires+prop) |
| Efficiency at rated thrust | 8.48g/W (8kg) |
| IP | IPX6 |
| Max. thrust | 22.7kg |
| Recommended ambient temperature | -20～55℃ |
