Viulinx PTMP mesh digital datalink

€0.00

1.4 GHz1.4 GHz
2.4 GHz2.4 GHz
5.8 GHz5.8 GHz
0.5 watt0.5 watt
1 watt1 watt
SKU: TS-Viulinx-PTMP-14-05Categories: Datalink & digital video
Description

Price on request

Product Details

  • Frequency:1.4GHz/2.4GHZ
  • Bandwidth:10MHz (uplink); 10MHz (downlink)
  • Power:27dBm-30dBm (100mW-1W)
  • Modulation:OFDM
  • Constellation:BPSK, QPSK, 16QAM
  • FEC:LDPC (1/2, 2/3, 3/4, 5/6)
  • Duplex:TDD
  • Throughputhroughput:up to 19 Mbps
  • Voltage:6-16V
  • Working temperature:-20°C ~55°C
  • Size of ground unit:77.8X47.3X23.5mm
  • Size of air unit:77.8X47.3X23.5mm
  • Weight :97g (air unit)
  • Video Interface:Ethernet
  • Other Interface:Serial, USB
  • Encryption:AES128/256
  • Network topology:Star
  • Node:1 master node, up to 6 slave nodes
  • Communication distance7km-100km (depending on number of nodes)
