Description
Price on request
Product Details
- Frequency：1.4GHz/2.4GHZ
- Bandwidth：10MHz (uplink); 10MHz (downlink)
- Power：27dBm-30dBm (100mW-1W)
- Modulation：OFDM
- Constellation：BPSK, QPSK, 16QAM
- FEC：LDPC (1/2, 2/3, 3/4, 5/6)
- Duplex：TDD
- Throughput：up to 19 Mbps
- Voltage：6-16V
- Working temperature：-20°C ~55°C
- Size of ground unit：77.8X47.3X23.5mm
- Size of air unit：77.8X47.3X23.5mm
- Weight：97g (air unit)
- Video Interface：Ethernet
- Other Interface：Serial, USB
- Encryption：AES128/256
- Network topology：Star
- Node：1 master node, up to 6 slave nodes
- Communication distance：7km-15km, 15km-30km, 30km-50km, 50km-100km
